- Types:
- Three rolls plate bending machine
- Model:
- 16*2000
- Inventory or not:
- No
- Main motor power:
- 15 kw
- Overall dimension:
- 4200 mm
- Maximum thickness of coiled plate:
- 16 mm
- Maximum width of coiled plate:
- 2000 mm
- Coil speed:
- 5 m/min
- Lower roll diameter:
- 220 mm
- Minimum diameter of full load rolling:
- 700 mm
- Power type:
- Mechanical transmission
- Control form:
- Artificial
- Layout form:
- Horizontal type
- Action object material:
- Metal
1) Upper and lower rollers: important parts of the bending machine, the material is refined forgings, rough turning forming leaves machining allowance, after quenching and temperingHB240~280, and then finish machining, * after quenchingHRC40~45. According to the requirements of encapsulation treatment, anti-surface strain. Conical rollers can also be made to roll conical cylinders to achieve higher cone rolling effect.
(2) frame: divided into left and right frame each one, for steel plate welded structural parts, after removing welding stress treatment, the frame has a lower roller bearing. A square screw rod is arranged in the frame, and the upper end of the screw rod is hinged with bearing seats at both ends of the upper roller. A worm gear pair and a screw pair are arranged at the lower part of the worm gear pair. The upper roller is raised or lowered by rotating the nut in the worm wheel.
(3) Support roller device: used for the support of the middle of the lower roller to improve the rigidity of the lower roller and thus improve the forming accuracy of the workpiece.
(4) Reducer: The main and auxiliary reducers are cylindrical gear reducers. Mounted on the work base together with the pad height.
(5) Discharge balance device: installed on one side of the reducer for balancing the upper roller during unloading.
(6) Overturn mechanism: installed on the upside down side for upside down and recovery.
(7) Base: It is an integral base for easy installation and lifting. It is welded by section steel and steel plate, and treated by removing stress. The frame, reducer, motor, etc. are installed on it to form a whole.
(8) Electrical part: three-phase380V/50HzAC power supply, a main motor drives the lower roller to rotate, and an auxiliary motor drives the upper roller to lift. The control electrical apparatus of this machine is installed in the control box and has short-circuit overheat protection. Electric cabinet can be placed according to operation needs, easy to operate.
- Name(chinese)
- 马鞍山市巨德机械科技有限公司
- Name(English)
- Maanshan City Jude Machinery Technology Co., Ltd.
- China credit code
- 913405065861445290 Identity Verification
- Registered Capital
- 2,000,000 CNY
- Operating term
- 2011-11-25 ~ ****
- Product Category
- Plate bending machine series
- Address
-
Anhui Maanshan, China
- Nearby port
- Shanghai
Jude Company is located in the Bowang Special Economic Zone of Maanshan City, Steel City. The company is committed to the development and sales of various ordinary and CNC machine tools (bending machines, plate shearing machines, punches, plate bending machines, joint punching and shearing machines, corner cutting machines, hydraulic presses, and other sheet metal equipment) and blade mold parts (forging dies, alloy tools, shaped tools, round tools, elongated tools, machine tool parts). Jude Company, which seeks development based on quality, regards quality control in the production process as important as advanced design. Adopt a modular production management and quality control system, while rationally allocating resources, while adhering to the quality concept of "meticulous and continuous improvement", and strictly in accordance with user requirements and the technical requirements of relevant national and industry standards, each process is carried out layer by layer inspection and check to ensure product quality and delivery time from every detail. Jude Company has always achieved maximum benefits for users, and its products are widely used in industries such as home appliances, elevators, military industry, engineering machinery, boilers, ships and container manufacturing. In the process of globalization, Jude Company will provide users with more advanced sheet metal processing equipment and high-precision tool accessories to further improve users 'economic benefits. All employees of the company never forget the corporate goal of "creating a first-class brand and building a first-class image", adhere to the corporate development policy of "striving for excellence in work and satisfying customer service", and work hand in hand with friends at home and abroad to create brilliance!- Name(chinese)
